26 Cubic Foot Humidity Chamber For Environmental Simulation, 0-70C Temperature Range, 10-80%RH Range, 120V

Binder KBF 720 Humidity Test Chamber For Environmental Testing Without Condensation - Lab Equipment - Stellar Scientific

26 Cubic Foot Humidity Chamber For Environmental Simulation, 0-70C Temperature Range, 10-80%RH Range, 120V

(No reviews yet) (No reviews yet)
SKU:
BIN-KBF-720-120
Weight:
730.00 LBS
Shipping:
Calculated at Checkout
$29,698.20 $27,999.00
(You save $1,699.20 )
Share:

The Binder KBF-720 humidity chamber create the perfect environment simulation in building physics, electronics, biology, zoology and botany.

Binder humidity chambers simulate the stress of humid temperature conditions without condensation build-up

Cooling with climate-neutral R-600a refrigerant

Binder KBF-720 humidity chamber is compliant with ICH Q1A guidelines, even with a full load.

Binder KBF-720 humidity chambers comes with two stainless steel electropolished shelves, sixteen total shelf capacity.

This unit is not stackable

Binder KBF-720 humidity chambers comes with an independent water tank and does not require external hook-up to generate humidity

Binder KBF-720 humidity chamber comes with a 80 x 45mm access port with a silicone plug

Data is recorded internally and is exportable via USB

Optional light modules to convert this chamber into a photostability chamber for ICH Q1B testing.

Optional LED light modules to convert this chamber into a plant growth chamber

Below is a chart showing the temperature range and conditions for humidity free performance:




Click on the icon below to download a brochure and learn more about Binder Humidity Test Chambers


Temperature Range With Humidity:
0 °C up to +70 °C
Operating Humidity Range:
10-80 % RH
Max Heat Compensation at 40C:
640W
Temperature uniformity at 25°C and 60% RH:
0.3 ± K
Temperature uniformity at 40°C and 75% RH:
0.2 ± K
Temperature fluctuation at 25°C and 60% RH:
0.1 ± K
Temperature fluctuation at 40°C and 75% RH:
0.1 ± K
Recovery time after door was opened for 30 s at 25°C and 60% RH:
1 Min
Recovery time after door was opened for 30 s at 40°C and 75% RH:
5 Min
Max Load Per Shelf:
88lbs
Maximum Loading Weight:
220lbs
Exterior Dimensions (W x H x D):
50.59” x 76.81” x 35.43”
Interior Dimensions (W x H x D):
39.8” x 49.21” x 22.64”
Shelving:
2 Included, Max 16
